FZQ-08 Fiber Optic Fan Out Kit
Material available:stainless steel/aluminum alloy/copper/iron/POM
Surface treatment:anodizing,electroplating,spray molding,passivation,laser laser
LOGO
Color:conventional color is blank,sliver white,customizable in any other
color.It is suitable for all round indoorcables,outdoor
cables,waterproof cables,armored cables,photoelecric composite
cables and FTTH cables.
Accessories:heat shrinkable tube,glue,protective sleeve,fixing
ring,screw,spanner.
Application:
- Bunch cable branch
- Armored fiber optic cable branch
- Field optical cable branch
- Various optical/cable branch solutions
Features:
- Material non-metal black
- POM material
- High temperature resistant to ROHS
- Fast and easy fixing
Product structure dimension drawing:
FZQ-08 product ordering information:
Core No. OD2
|
Core Dia OD2
| OD Cable Dia | OD1
Product Dia | L
Product Lenths |
material
|
| 1 | 2core | 1 | 0.9mm | 1 | 3.0mm | 1 | 10mm | 1 | 20mm | 1 | POM |
| 2 | 4core | 2 | 1.6mm | 2 | 5.0mm | 2 | 12mm | 2 | 35mm | 2 | Aluminum alloy |
| 3 | 6core | 3 | 2.0mm | 3 | 7.0mm | 3 | 14mm | 3 | 43mm | 3 | copper |
| 4 | 8core | 4 | 3.0mm | 4 | Other | 4 | 18mm | 4 | 50mm | 4 | Stainless steel |
| 5 | 12core | 5 | Other | | | 5 | Other | 5 | Other | 5 | Other |
| 6 | 24core | | | | | | | | | | |
| 7 | Other | | | | | | | | | | |
Product Description
The bare fiber of multi-core optical cable is easy to break off.
This product can fix branch and cable protection pipe to make the
optical fiber data more stable, secure and beautiful.The fixing
methods of products generally include metal ring fixation, glue
fixation, extrusion deformation and so on.
Optical fiber protection tube is to protect the 125 mu m bare fiber
optic fiber is not easy damaged, worn outside casing protection
strengthen (usually use 0.9 mm to 2.0 mm to 3.0 mm or other metal
specifications) port we called the branch end fixed station
(customer called the output or input)
The kits provide the most compact, easy-to-install fan-out solution
requiring no additional hardware or space than that required for
terminating tight-buffered cables. Indoor kits feature a 900 um
fan-out assembly that is color coded to match the fiber color
scheme. The fan-out assembly is available with 6- or 12-fiber units
in lengths of 0.6 m (25 in) or 1.2 m (47 in). These different
lengths provide the installer the flexibility needed for a variety
of hardware options.
other product:Our company can customize design and develop new products according
to customer needs
